At Kolbe, we want to make it easier for you create your vision for contemporary projects. Therefore, we have added elevation drawings for many VistaLuxe^® Collection products to the Architect Library (see Resources). These drawings include:

• Casements & Awnings
• Inswing & Outswing Doors, Transoms and Sidelites
• Direct Sets
• Sliding Patio Doors & Transoms
• Single, Double, Triple and Quad Sliding Windows

ID: ELEVATIONSHEET

VistaLuxe elevation drawings are available in DWG, DXF and PDF formats for various uses. Single files may be downloaded, or several files may be selected and saved to a folder for a single download of multiple files and/or file types.

Elevations are one more tool to help you include VistaLuxe Collection and Complementary windows and doors in your projects.

To view VistaLuxe elevation drawings, go to Resources, select the Architect Library, select VistaLuxe Collection, select an operation(s), and then select "Elevation Charts."
