ID: AF448

Ultra SeriesCrank-Out Casements

Ready To Get Started?

See Product In Person

Tailor Your Style with Custom Options & Finishes

Aesthetic

Versatile styling from traditional to modern designs

Material

Interior: Wood
Exterior: Extruded Aluminum

Sizing

Max Width: 42” x 77”
Max Height: 33” x 96”

XL units up to 48” x 84” or 42” x 96”

Configurations

French units, bows, bays, radius-top shapes, and combined units

Operation

Swing out at the side to provide fresh air

Performance

Impact units for hurricane-prone coastal areas meet IPD4

Colors & Finishes: A Palette of Possibilities

Ultra Pure White

About Fluoropolymer Finishes

Kolbe’s aluminum-clad windows and doors are available in a range of high-performance exterior finishes designed for exceptional durability, chemical resistance, abrasion, corrosion protection, and long-term weathering performance. In addition to the standard palette, custom colors can be specified, as well as Anodized aluminum and Mica fluoropolymer finishes.

Notes

Finish colors may vary from on-screen images. Please make selections using actual color samples available from your local Kolbe dealer.

Selected Options:

Double Clear Coat

About Interior Stain

Kolbe products can be finished on the interior with a water-based, low-VOC stain. After staining, a clear coat is applied, the surface is sanded, and a second clear coat is applied. Custom colors may be requested as well.

Notes

The stain colors are shown on Pine.

Finish colors may vary from on-screen images. Please make selections using actual color samples available from your local Kolbe dealer.

Selected Options:

Materials: Crafting Strength with Elegant Design

Extruded Aluminum Cladding

About Extruded Aluminum Cladding

A durable exterior helps safeguard the beauty of windows and doors, and helps prevent damage during harsh weather. This product has durable cladding of 6063 extruded aluminum alloy that is press-fit onto the exterior of the wood. Accessory grooves are integral to the frame exterior, which allows for factory or job site installation of extruded aluminum casing, sill nosing, and other exterior trim.

Note

This photo is an Ultra Series inswing entrance door with extruded aluminum cladding on the exterior. It is meant to represent the exterior material; it is not necessarily representative of how the product on this page is constructed.

Selected Options:

Double Pane

About Performance Glass

There's so much more to window and door glass than visibility. Today's technology helps windows and doors achieve strict energy efficiency standards in a wide variety of climate conditions. For more information, please see Glass Terminology.

Notes

Not all glass is available on all products. Please contact your Kolbe dealer for product specifics.

Low-E insulating glass with a stainless steel spacer bar carries a 20-year warranty. Not all glass options listed have the same glass warranty. Please contact your dealer for details.

Selected Options:

Styles & Lites

Beveled Profile PDL Bars

(5/8")

About Performance Divided Lites

With Kolbe's performance divided lite (PDL) system, bars are adhered on the interior and exterior of an insulating glass unit and bars aligned within the unit.

PDL bars are available in various widths and patterns. They may be finished to match the exterior and/or interior, as requested.

Notes

Limitations may apply. Please consult your local Kolbe dealer for more information.

Selected Options:

1-15/16" Brickmould

About Extruded Aluminum Casing

Casing helps define the architectural design of a structure. It frames the curbside view of windows and doors, and can evoke a period style. Ultra Series casing has been designed to be aesthetically similar to wood trim. Because it is extruded aluminum rather than wood, however, it offers greater durability and rigidity. It is usually finished the same color as the window unit, but can be a contrasting color for visual impact.

Notes

Limitations apply when combining trim options; i.e., not all brickmould profiles can be combined with all sill nosing profiles. Not all profiles are available for radius units.

Custom trim profiles may be available upon request. Please consult your local Kolbe dealer for more information.

Selected Options:

Screens


BetterVue® Insect Screen Mesh

About Screen Mesh

Various types of screen mesh are available to keep insects from entering open windows and doors. Most Kolbe windows and doors have BetterVue® fiberglass mesh, which is less visible than many screens in the industry. Plus, the tighter weave keeps smaller bugs out, is flame retardant, and doesn't stain, crease or dent.

For even better visibility, request UltraVue® mesh. Both BetterVue and UltraVue are GreenGuard®-certified, meaning that they meet strict chemical emissions limits for healthier interiors. Plus, they have the added value of Water Shed Technology™, which is an advanced water repellent coating that allows screens to repel water and debris. It increases the life expectancy of the screens by keeping them cleaner longer. Water beads up and rolls off, to preserve viewing clarity, rain or shine. As you can see, the view remains much more visible when screens have Water Shed Technology applied (left side of Water Shed photo), as opposed to those without it (right side of Water Shed photo).

Aluminum screen mesh is available for areas with fiberglass screen-eating insects.

Notes

Limitations may apply. Please consult your local Kolbe dealer for more details.

BetterVue® and UltraVue® are registered trademarks of PHIFER INCORPORATED.

Water Shed Technology™ is a trademark of PHIFER INCORPORATED.

Selected Options:

Hardware & Operation

Crank-Out Nesting Handles

(Satin Nickel)

About Handles & Locks

Crank-out handles fold down and "nest" when not in use. For a more contemporary look, Ashlar handles are available. Multi-point locks engage with a locking lever.

Notes

*Oil-rubbed is a living finish that will change appearance with time and use.

Finish colors may vary from on-screen images. Please make selections using actual color samples available from your local Kolbe dealer.

Selected Options:

Universal Design

Larger Handles

About Accessible Hardware

Universal design is the concept of making products and spaces accessible for people with various physical ability levels. It promotes freedom for people with disabilities. It allows the elderly to live independently longer. Kolbe's options can help.

Notes

These options may meet standards of the Americans with Disabilities Act. Certain product limitations and modifications may apply. Please contact your local Kolbe dealer for more information.

Selected Options:
